Nyan Cat

Flow description

# Nyan Cat - draws the 32x8 animated GIF and plays the melody under it.
#
# The app starts the tune the first time it is shown, keeps the GIF on screen
# while the buzzer is playing, and steps aside once the last note has sounded.
# A press on any button stops both and lets the rotation move on.
#
# Needs an icon called "nyan" (a 32x8 GIF) and a melody called "nyancat".
#
# @author  QINZY8
# @name    Nyan Cat
# @desc    Nyan Cat GIF with the tune under it.
# @config  melody  bool    "Play the melody"  default=true  help="Off shows the GIF for the usual app duration instead"
# @config  tune    text    "Melody name"      default="nyancat"  maxlen=24
# @config  icon    text    "Icon name"        default="nyan"  maxlen=24
# @config  volume  slider  "Volume"           default=100  min=0  max=100  unit=%  help="Restored to the device setting after the tune"

class Nyan
  var started          # the tune has been kicked off for this appearance
  var stopping         # the user asked to stop, so do not linger
  var savedVolume      # the buzzer volume to put back, or nil when untouched

  def init()
    self.started = false
    self.stopping = false
    self.savedVolume = nil
  end

  # With the melody off there is nothing to wait for, so the rotation keeps its
  # own clock and the app behaves like any other: a plain duration, no pause.
  def wants_melody()
    return store.get("melody") != false
  end

  # The volume is a device-wide setting, not a per-app one, so this app borrows
  # it for the length of the tune and hands it back. Without the restore a
  # quieter cat would leave every later melody quiet too.
  def apply_volume()
    if self.savedVolume != nil return end
    self.savedVolume = settings.get("buzzerVolume")
    settings.set("buzzerVolume", store.get("volume"))
  end

  def restore_volume()
    if self.savedVolume == nil return end
    settings.set("buzzerVolume", self.savedVolume)
    self.savedVolume = nil
  end

  # on_show() runs the moment the rotation brings this app in, before the first
  # draw(), so the GIF is already on screen when the first note lands. This is
  # the one hook that fires exactly once per appearance.
  def on_show()
    self.stopping = false
    if !self.wants_melody()
      self.started = false
      return
    end
    self.apply_volume()
    sound.melody(store.get("tune"))
    self.started = true
    # Hold the rotation while the tune plays: the melody is the clock, and a
    # fixed duration cannot know how long it runs. resume() in loop() releases
    # it once the last note has sounded.
    rotation.pause()
  end

  # Leaving the screen stops the tune: the melody belongs to the picture, and a
  # rotation that moved on must not leave it playing behind another app. The
  # volume goes back with it.
  def on_hide()
    if self.started sound.stop() end
    self.started = false
    self.restore_volume()
  end

  # Only takes a turn in the rotation when there is something to play. On a
  # device with no buzzer, or with sound switched off, this app stays out of
  # the way instead of showing a silent cat - unless the melody is off, in
  # which case it is a plain GIF and runs anywhere.
  def should_show()
    if !self.wants_melody() return true end
    if !sound.sinks()['buzzer'] return false end
    return settings.get("soundEnabled") != false
  end

  # With the melody off, ask for the usual slot so the rotation has a clock to
  # work from. With it on, loop() ends the appearance instead.
  def duration()
    if self.wants_melody() return 60000 end
    return 0
  end

  # loop() runs about once a second, on screen or not, and is where the tune is
  # watched. draw() must not do this: it runs per frame, so checking there
  # would be 40 times the work for the same answer.
  def loop()
    if !self.started return end
    # The last note has sounded, or the user stopped it: hand the panel back.
    if self.stopping || !sound.playing()
      self.stopping = true
      self.started = false
      self.restore_volume()
      rotation.resume()
      rotation.next()
    end
  end

  def draw()
    clear()
    # The GIF animates on its own clock, so nothing here has to count frames.
    if !icon(store.get("icon"), 0, 0)
      # No icon stored: say so rather than showing an empty panel.
      font("small")
      text(1, 6, "no nyan", 0xFF00FF)
    end
  end

  # A press stops the tune and leaves at once, which is what a viewer expects
  # from a jingle that has worn out its welcome.
  def on_button(btn)
    self.stopping = true
    if self.started
      sound.stop()
      self.restore_volume()
      rotation.resume()
    end
    rotation.next()
    return true
  end
end

return Nyan()

These icons are attached to the flow. Send them to your AWTRIX separately; they are not included in the script installation.

Sign in to download these icons or send them to your AWTRIX.
