FlightRadar

Flow description

# @name FlightRadar
# @desc Nearest 3 aircraft via adsb.fi
# @version 1.5-lite
# @config lat text "Latitude" default="31.2304" maxlen=16
# @config lon text "Longitude" default="121.4737" maxlen=16
# @config radius number "Radius" default=100 min=5 max=450 step=5 unit=km
# @config refresh number "Refresh Interval" default=30 min=15 max=300 unit=s
# @config page number "Page Duration" default=3 min=2 max=8 unit=s
# @config overhead number "Overhead Distance" default=5 min=1 max=30 unit=km
# @config alert bool "Overhead Alert" default=true
# @config emergency bool "Emergency Alert" default=true
# @config alertsec number "Notification Duration" default=8 min=3 max=30 unit=s
# @config tint color "Aircraft Color" default=#33AAFF

class FlightRadar
  var url
  var ticks
  var busy
  var pages
  var count
  var status
  var error
  var shown
  var page_ms
  var color
  var nhex
  var nflight
  var ndist
  var nalt
  var nspd
  var ntrk
  var ndir
  var last_over
  var last_emg
  var opts

  def init()
    var km = store.get("radius")
    if km == nil km = 100 end
    if km < 5 km = 5 end
    if km > 463 km = 463 end

    var nm = int(km / 1.852)
    if nm < 1 nm = 1 end
    if nm > 250 nm = 250 end

    self.url = "https://opendata.adsb.fi/api/v3/lat/" +
      store.get("lat") + "/lon/" + store.get("lon") +
      "/dist/" + str(nm)

    self.ticks = 0
    self.busy = false
    self.pages = []
    self.count = 0
    self.status = "SCAN..."
    self.error = false
    self.shown = now_ms()
    self.page_ms = store.get("page") * 1000
    self.color = store.get("tint")
    if self.color == nil self.color = 0x33AAFF end

    self.nhex = nil
    self.nflight = nil
    self.ndist = nil
    self.nalt = nil
    self.nspd = nil
    self.ntrk = nil
    self.ndir = ""
    self.last_over = nil
    self.last_emg = nil

    self.opts = {
      "mode":"wrap",
      "speed":75,
      "holdMs":500
    }

    shared.set("active", false)
    shared.set("count", 0)
    shared.set("status", "scan")
  end

  def dir(v)
    if v == nil return "" end
    if v >= 337.5 || v < 22.5 return "N" end
    if v < 67.5 return "NE" end
    if v < 112.5 return "E" end
    if v < 157.5 return "SE" end
    if v < 202.5 return "S" end
    if v < 247.5 return "SW" end
    if v < 292.5 return "W" end
    return "NW"
  end

  def emg(s)
    if s == "7500" return "HIJACK" end
    if s == "7600" return "RADIO" end
    if s == "7700" return "EMERG" end
    return nil
  end

  def km1(v)
    var n = int(v * 10 + 0.5)
    return str(int(n / 10)) + "." + str(n % 10) + "KM"
  end

  def on_body(body, st)
    self.busy = false

    if st == 0
      self.error = true
      self.status = "NET ERR"
      shared.set("status", "network")
      return
    end

    if st != 200
      self.error = true
      self.status = "HTTP " + str(st)
      shared.set("status", self.status)
      return
    end

    if body == nil
      self.pages = []
      self.count = 0
      self.status = "NO FLT"
      self.error = false
      self.nhex = nil
      self.last_over = nil
      self.last_emg = nil

      shared.set("active", false)
      shared.set("count", 0)
      shared.set("status", "empty")
      return
    end

    var ps = re.matchall(
      "[{][^{}]*\"hex\":\"[A-Za-z0-9]+\"[^{}]*[}]",
      body
    )

    if ps == nil || size(ps) == 0
      self.pages = []
      self.count = 0
      self.status = "NO FLT"
      self.error = false

      shared.set("active", false)
      shared.set("count", 0)
      shared.set("status", "empty")
      return
    end

    var bo = [nil,nil,nil]
    var bd = [999999.0,999999.0,999999.0]
    var fb = []

    var ehex = nil
    var eflight = nil
    var esq = nil

    for p : ps
      if size(fb) < 3
        fb.push(p)
      end

      var q = re.search(
        "\"squawk\":\"([0-9]+)\"",
        p
      )

      if q != nil &&
         self.emg(q[1]) != nil &&
         esq == nil

        esq = q[1]

        var eh = re.search(
          "\"hex\":\"([A-Za-z0-9]+)",
          p
        )

        if eh != nil
          ehex = eh[1]
        end

        var ef = re.search(
          "\"flight\":\"[ ]*([A-Za-z0-9]+)",
          p
        )

        if ef != nil
          eflight = ef[1]
        else
          eflight = ehex
        end
      end

      var md = re.search(
        "\"dst\":([0-9.]+)",
        p
      )

      if md != nil
        var d = num(md[1])

        if d != nil
          if d < bd[0]
            bd[2] = bd[1]
            bo[2] = bo[1]

            bd[1] = bd[0]
            bo[1] = bo[0]

            bd[0] = d
            bo[0] = p

          elif d < bd[1]
            bd[2] = bd[1]
            bo[2] = bo[1]

            bd[1] = d
            bo[1] = p

          elif d < bd[2]
            bd[2] = d
            bo[2] = p
          end
        end
      end
    end

    if bo[0] == nil
      var j = 0

      while j < size(fb) && j < 3
        bo[j] = fb[j]
        bd[j] = -1
        j += 1
      end
    end

    var out = []
    var c = 0
    var i = 0

    self.nhex = nil
    self.nflight = nil
    self.ndist = nil
    self.nalt = nil
    self.nspd = nil
    self.ntrk = nil
    self.ndir = ""

    while i < 3
      var p = bo[i]

      if p != nil
        var mh = re.search(
          "\"hex\":\"([A-Za-z0-9]+)",
          p
        )

        if mh != nil
          var hx = mh[1]

          var mf = re.search(
            "\"flight\":\"[ ]*([A-Za-z0-9]+)",
            p
          )

          var fl = hx

          if mf != nil
            fl = mf[1]
          end

          var dist = nil

          if bd[i] >= 0
            dist = bd[i] * 1.852
          end

          var alt = nil

          var ma = re.search(
            "\"alt_baro\":([-0-9.]+)",
            p
          )

          if ma != nil
            alt = num(ma[1])
          else
            ma = re.search(
              "\"alt_geom\":([-0-9.]+)",
              p
            )

            if ma != nil
              alt = num(ma[1])
            end
          end

          var sp = nil

          var ms = re.search(
            "\"gs\":([0-9.]+)",
            p
          )

          if ms != nil
            sp = num(ms[1])
          end

          var tr = nil

          var mt = re.search(
            "\"track\":([0-9.]+)",
            p
          )

          if mt != nil
            tr = num(mt[1])
          end

          var di = self.dir(tr)

          # Page 1: flight + distance
          var p1 =
            str(i + 1) + " " + fl

          if dist != nil
            p1 =
              p1 + " " +
              self.km1(dist)
          end

          # Page 2: altitude + speed + direction
          var p2 = str(i + 1)

          if alt != nil
            if alt >= 1000
              p2 =
                p2 + " " +
                str(
                  int(
                    (alt + 500) /
                    1000
                  )
                ) +
                "K"
            else
              p2 =
                p2 + " " +
                str(int(alt)) +
                "FT"
            end
          end

          if sp != nil
            p2 =
              p2 + " " +
              str(int(sp)) +
              "KT"
          end

          if di != ""
            p2 =
              p2 + " " +
              di
          end

          out.push(p1)
          out.push(p2)

          c += 1

          # Nearest aircraft
          if i == 0
            self.nhex = hx
            self.nflight = fl
            self.ndist = dist
            self.nalt = alt
            self.nspd = sp
            self.ntrk = tr
            self.ndir = di
          end
        end
      end

      i += 1
    end

    self.pages = out
    self.count = c
    self.error = false

    if c > 0
      self.status = "LIVE"
      shared.set("status", "ok")
    else
      self.status = "NO FLT"
      shared.set("status", "empty")
    end

    shared.set("active", c > 0)
    shared.set("count", c)

    # Shared: nearest aircraft
    if self.nhex != nil
      shared.set(
        "flight",
        self.nflight
      )

      shared.set(
        "hex",
        self.nhex
      )

      if self.ndist != nil
        shared.set(
          "distance_km",
          self.ndist
        )
      else
        shared.set(
          "distance_km",
          -1
        )
      end

      if self.nalt != nil
        shared.set(
          "altitude_ft",
          self.nalt
        )
      else
        shared.set(
          "altitude_ft",
          -1
        )
      end

      if self.nspd != nil
        shared.set(
          "speed_kt",
          self.nspd
        )
      else
        shared.set(
          "speed_kt",
          -1
        )
      end

      if self.ntrk != nil
        shared.set(
          "heading_deg",
          self.ntrk
        )
      else
        shared.set(
          "heading_deg",
          -1
        )
      end

      shared.set(
        "direction",
        self.ndir
      )
    end

    # ==========================================
    # Overhead aircraft alert
    # ==========================================

    if store.get("alert") &&
       self.nhex != nil &&
       self.ndist != nil &&
       self.ndist <= store.get("overhead")

      if self.nhex != self.last_over
        notify({
          "text":
            "OVERHEAD " +
            self.nflight +
            " " +
            self.km1(self.ndist),

          "textColor":
            0xFFFF00,

          "durationMs":
            store.get("alertsec") *
            1000,

          "wakeup":
            true,

          "stack":
            false
        })

        self.last_over =
          self.nhex
      end

    elif self.ndist == nil ||
         self.ndist > store.get("overhead")

      self.last_over = nil
    end

    # ==========================================
    # 7500 / 7600 / 7700
    # ==========================================

    if esq != nil &&
       store.get("emergency")

      var eid =
        ehex + ":" + esq

      if eid != self.last_emg
        notify({
          "text":
            self.emg(esq) +
            " " +
            esq +
            " " +
            eflight,

          "textColor":
            0xFF0000,

          "durationMs":
            store.get("alertsec") *
            1000,

          "wakeup":
            true,

          "stack":
            false
        })

        self.last_emg = eid
      end

    else
      self.last_emg = nil
    end
  end


  # ============================================
  # Periodically fetch aircraft data
  # ============================================

  def loop()
    if self.ticks <= 0
      var r = store.get("refresh")

      if r == nil || r < 15
        r = 30
      end

      self.ticks = r

      if !self.busy
        self.busy = true

        if self.count == 0 &&
           !self.error

          self.status =
            "SCAN..."
        end

        http.get(
          self.url,

          / b, st ->
            self.on_body(b, st),

          {
            "find":
              "\"ac\":[",

            "keep":
              8192,

            "headers":{
              "User-Agent":
                "AWTRIX-NG/FlightRadar",

              "Accept":
                "application/json"
            }
          }
        )
      end
    end

    self.ticks -= 1
  end


  def on_show()
    self.shown = now_ms()
  end


  # Show all aircraft pages before switching to the next app
  def duration()
    var n = size(self.pages)

    if n < 1
      return self.page_ms
    end

    return self.page_ms * n
  end


  # ============================================
  # Aircraft icon
  # ============================================

  def draw_plane()
    var x =
      int(now_ms() / 500) % 2

    # Fuselage
    line(
      x + 3,
      0,
      x + 3,
      7,
      self.color
    )

    # Wings
    line(
      x,
      3,
      x + 6,
      3,
      self.color
    )

    pixel(
      x + 1,
      2,
      self.color
    )

    pixel(
      x + 5,
      2,
      self.color
    )

    # Tail
    line(
      x + 2,
      6,
      x + 4,
      6,
      self.color
    )

    # Red flashing light
    if now_ms() % 1000 < 150
      pixel(
        x + 6,
        3,
        0xFF0000
      )
    end
  end


  # ============================================
  # Rendering
  # ============================================

  def draw()
    clear()

    self.draw_plane()

    if self.error
      pixel(
        width() - 1,
        0,
        0xFF0000
      )
    end

    var label =
      self.status

    var col =
      0x666666

    var n =
      size(self.pages)

    if n > 0
      var p =
        int(
          (now_ms() - self.shown) /
          self.page_ms
        ) % n

      label =
        self.pages[p]

      col =
        settings.get("textColor")

      if col == nil
        col = 0xFFFFFF
      end

    elif self.error
      col = 0xFF4444
    end

    scroll_text(
      8,
      6,
      width() - 8,
      label,
      col,
      self.opts
    )
  end

end

return FlightRadar()
