Weather Script

Flow description

# @name    Alta Weather
# @desc    Current weather and temperature for Alta Norway
# @author  Hank_the_Tank / bagrue
# @version 2.4

# @config  latitude   number "Latitude"     default=69.97 min=-90 max=90 step=0.01
# @config  longitude  number "Longitude"    default=23.27 min=-180 max=180 step=0.01
# @config  refresh    number "Refresh"      default=5 min=1 max=60 unit=min
# @config  unit       select "Temperature"  default=C options=C,F


class Weather

  var tcol
  var wic
  var ticks
  var age
  var url
  var period
  var temp_value
  var temp_negative
  var font


  def init()

    self.tcol = 0x666666
    self.wic = "36637"
    self.ticks = 0
    self.age = 9999
    self.temp_value = 0
    self.temp_negative = false

    self.period = store.get("refresh") * 60

    self.url = "https://api.open-meteo.com/v1/forecast" +
               "?latitude=" + str(store.get("latitude")) +
               "&longitude=" + str(store.get("longitude")) +
               "&current=temperature_2m,weather_code" +
               "&timezone=auto"

    # Kompakt 6 x 7-pikslers font.
    # Hvert tall består av sju rader.
    self.font = [
    # 0
    [30, 51, 51, 51, 51, 51, 30],

    # 1
    [12, 28, 12, 12, 12, 12, 63],

    # 2
    [30, 51, 3, 14, 24, 51, 63],

    # 3
    [30, 51, 3, 14, 3, 51, 30],

    # 4
    [6, 14, 22, 38, 63, 6, 7],

    # 5
    [63, 48, 62, 3, 3, 51, 30],

    # 6
    [14, 24, 48, 62, 51, 51, 30],

    # 7
    [63, 51, 3, 6, 12, 12, 12],

    # 8
    [30, 51, 51, 30, 51, 51, 30],

    # 9
    [30, 51, 51, 31, 3, 6, 28]
   ]

  end


  # --------------------------------------------------
  # TEGN ETT TALL
  # --------------------------------------------------

  def digit(x, n)

    var row = 0

    while row < 7

      var bits = self.font[n][row]
      var col = 0

      while col < 6

        if (bits & (1 << (5 - col))) != 0
          pixel(x + col, row, self.tcol)
        end

        col += 1

      end

      row += 1

    end

  end


  # --------------------------------------------------
  # MINUSTEGN
  # --------------------------------------------------

  def minus(x)

    var col = 0

    while col < 5

      pixel(x + col, 3, self.tcol)
      col += 1

    end

  end


  # --------------------------------------------------
  # GRADTEGN
  # --------------------------------------------------

  def degree(x)

    pixel(x + 2, 0, self.tcol)
    pixel(x + 3, 0, self.tcol)

    pixel(x + 1, 1, self.tcol)
    pixel(x + 4, 1, self.tcol)

    pixel(x + 1, 2, self.tcol)
    pixel(x + 4, 2, self.tcol)

    pixel(x + 2, 3, self.tcol)
    pixel(x + 3, 3, self.tcol)

  end


  # --------------------------------------------------
  # TEGN TEMPERATUREN
  # --------------------------------------------------

  def draw_temperature()

    var t = self.temp_value
    var x = 11

    # Minustegn
    if self.temp_negative

      self.minus(x)
      x += 7

    end

    # Ett tall
    if t < 10

      self.digit(x, t)
      x += 7

    # To tall
    else

      var tens = int(t / 10)
      var ones = t - tens * 10

      self.digit(x, tens)
      x += 7

      self.digit(x, ones)
      x += 7

    end

    # Gradtegn
    self.degree(x + 1)

  end


  # --------------------------------------------------
  # MOTTA VÆRDATA
  # --------------------------------------------------

  def on_body(body, status)

    if body == nil
      return
    end

    if status != 200
      return
    end

    var m = re.search(
      "temperature_2m\":([-0-9.]+)",
      body
    )

    var c = re.search(
      "weather_code\":([0-9]+)",
      body
    )

    if m == nil || c == nil
      return
    end

    # Berry bruker real(), ikke num().
    var t = real(m[1])

    # Celsius eller Fahrenheit
    var u = store.get("unit")

    if u == "F"
      t = t * 1.8 + 32
    end

    # Temperaturfarge
    if t > 20

      self.tcol = 0xFF0000

    elif t < 0

      self.tcol = 0x0080FF

    else

      self.tcol = 0xFFFFFF

    end

    # Rund av uten ternary-operator
    var ti

    if t >= 0
      ti = int(t + 0.5)
    else
      ti = int(t - 0.5)
    end

    # Lagre minus separat
    if ti < 0

      self.temp_negative = true
      self.temp_value = 0 - ti

    else

      self.temp_negative = false
      self.temp_value = ti

    end

    # Værkode
    var k = int(c[1])
    var ic = "36637"

    if k == 0

      # Klarvær
      ic = "53386"

    elif k <= 2

      # Delvis skyet
      ic = "2286"

    elif k == 3

      # Overskyet
      ic = "53384"

    elif k <= 48

      # Tåke
      ic = "17055"

    elif k <= 67

      # Regn
      ic = "2720"

    elif k <= 77

      # Snø
      ic = "2289"

    elif k <= 82

      # Regnbyger
      ic = "49300"

    elif k <= 86

      # Snøbyger
      ic = "2289"

    elif k >= 95

      # Tordenvær
      ic = "29839"

    end

    self.wic = ic
    self.age = 0

  end


  # --------------------------------------------------
  # OPPDATERING
  # --------------------------------------------------

  def loop()

    self.age += 1

    if self.ticks <= 0

      self.ticks = self.period

      http.get(
        self.url,
        /body, status -> self.on_body(body, status),
        {
          "find": "\"current\":",
          "keep": 256
        }
      )

    end

    self.ticks -= 1

  end


  # --------------------------------------------------
  # SKJERM
  # --------------------------------------------------

  def draw()

    clear()

    # Værikon
    if !icon(self.wic, 0, 0)
      circle_fill(4, 4, 3, 0xFFCC00)
    end

    # Temperatur
    if self.age < 9999

      self.draw_temperature()

    else

      text(6, 6, "...", 0x666666)

    end

    # Rød prikk hvis værdataene er gamle
    if self.age > 1200
      pixel(width() - 1, height() - 1, 0xFF0000)
    end

  end


  # --------------------------------------------------
  # KNAPP
  # --------------------------------------------------

  def on_button(btn)

    if btn == "select"
      self.ticks = 0
    end

  end

end


return Weather()

This flow uses the following icons. Add them to your AWTRIX along with the flow.

Sign in to download these icons or send them to your AWTRIX.
