Pixel Aquarium
Pixel Aquarium turns your AWTRIX NG into a tiny living underwater world.
AWTRIX NG Scripts
AWTRIX NG
About this flow
| System | AWTRIX NG Scripts |
|---|---|
| AWTRIX version | AWTRIX NG |
| Topic | Miscellaneous |
| Built by | Galadril |
| File | L44U7FojKRGZ.ax · 8.1 KB |
| Icons | — |
| Published | 8 Sep 2026 |
| Downloads | 32 |
Is this your flow?
If you created this flow, open your saved edit link to add it to your account. You can then manage it whenever you sign in. Adding it to your account replaces the edit link.
Flow description
Pixel Aquarium turns your AWTRIX NG into a tiny living underwater world. Colorful fish swim at different speeds and depths, occasionally leaving the screen as new species arrive. Bubbles rise from the plants and treasure chest, while rocks and sand create a cozy aquarium scene. Press the select button to drop food and watch the fish react. At night, the aquarium dims and the fish slow down. A relaxing little companion for your desk, with no goals or pressure.
L44U7FojKRGZ.ax
# @name Pixel Aquarium
# @desc A tiny living aquarium for your AWTRIX NG
# @version 0.1
import math
class PixelAquarium
var fish1_x
var fish1_y
var fish1_dir
var fish2_x
var fish2_y
var fish2_dir
var bubble1_x
var bubble1_y
var bubble2_x
var bubble2_y
var bubble3_x
var bubble3_y
var food_x
var food_y
var feeding
var last_move
var last_bubble
var last_food
def init()
self.fish1_x = 5
self.fish1_y = 2
self.fish1_dir = 1
self.fish2_x = 23
self.fish2_y = 5
self.fish2_dir = -1
self.bubble1_x = 8
self.bubble1_y = 6
self.bubble2_x = 17
self.bubble2_y = 4
self.bubble3_x = 27
self.bubble3_y = 7
self.food_x = 16
self.food_y = 0
self.feeding = false
self.last_move = 0
self.last_bubble = 0
self.last_food = 0
end
# --------------------------------------------------
# DAY / NIGHT
# --------------------------------------------------
def is_night()
var h = hour()
if h < 0
return false
end
if h >= 22 || h < 7
return true
end
return false
end
# --------------------------------------------------
# BUTTON
# --------------------------------------------------
def on_button(btn)
if btn == "select"
self.food_x = 6 + (math.rand() % 21)
self.food_y = 0
self.feeding = true
self.last_food = now_ms()
end
end
# --------------------------------------------------
# ANIMATION
# --------------------------------------------------
def update_fish()
var t = now_ms()
var speed = 350
if self.feeding
speed = 180
end
if self.is_night()
speed = 700
end
if t - self.last_move < speed
return
end
self.last_move = t
# Fish 1
if self.feeding
if self.fish1_x < self.food_x
self.fish1_dir = 1
elif self.fish1_x > self.food_x
self.fish1_dir = -1
end
end
self.fish1_x += self.fish1_dir
if self.fish1_x >= width() - 4
self.fish1_dir = -1
end
if self.fish1_x <= 1
self.fish1_dir = 1
end
# Fish 2 moves a little less predictably
if (math.rand() % 12) == 0
self.fish2_dir = self.fish2_dir * -1
end
self.fish2_x += self.fish2_dir
if self.fish2_x >= width() - 4
self.fish2_dir = -1
end
if self.fish2_x <= 1
self.fish2_dir = 1
end
end
def update_bubbles()
var t = now_ms()
if t - self.last_bubble < 320
return
end
self.last_bubble = t
self.bubble1_y -= 1
self.bubble2_y -= 1
self.bubble3_y -= 1
if self.bubble1_y < 0
self.bubble1_y = 6
self.bubble1_x = 3 + (math.rand() % 26)
end
if self.bubble2_y < 0
self.bubble2_y = 6
self.bubble2_x = 3 + (math.rand() % 26)
end
if self.bubble3_y < 0
self.bubble3_y = 6
self.bubble3_x = 3 + (math.rand() % 26)
end
end
def update_food()
if !self.feeding
return
end
var t = now_ms()
if t - self.last_food < 450
return
end
self.last_food = t
self.food_y += 1
if self.food_y >= 7
self.feeding = false
return
end
# Fish reached the food
var dx = self.fish1_x - self.food_x
if dx < 0
dx = dx * -1
end
var dy = self.fish1_y - self.food_y
if dy < 0
dy = dy * -1
end
if dx <= 2 && dy <= 1
self.feeding = false
end
end
# --------------------------------------------------
# BACKGROUND
# --------------------------------------------------
def draw_water()
if self.is_night()
clear(0x000008)
else
clear(0x000018)
end
end
def draw_sand()
var sand = 0xD6A434
if self.is_night()
sand = 0x392A12
end
rect_fill(0, 7, width(), 1, sand)
pixel(2, 7, 0x8A6325)
pixel(11, 7, 0xF0C052)
pixel(20, 7, 0x8A6325)
pixel(29, 7, 0xF0C052)
end
def draw_plants()
var green1 = 0x00AA44
var green2 = 0x00DD66
if self.is_night()
green1 = 0x003318
green2 = 0x005522
end
var sway = (now_ms() / 500) % 2
# left plant
pixel(2, 6, green1)
pixel(2, 5, green2)
pixel(3, 4, green1)
if sway == 0
pixel(2, 3, green2)
else
pixel(4, 3, green2)
end
# middle plant
pixel(14, 6, green2)
pixel(14, 5, green1)
if sway == 0
pixel(13, 4, green2)
pixel(15, 3, green1)
else
pixel(15, 4, green2)
pixel(13, 3, green1)
end
# right plant
pixel(29, 6, green1)
pixel(29, 5, green2)
pixel(28, 4, green1)
if sway == 0
pixel(30, 3, green2)
else
pixel(27, 3, green2)
end
end
def draw_rocks()
var rock = 0x666666
if self.is_night()
rock = 0x222222
end
pixel(6, 6, rock)
pixel(7, 6, rock)
pixel(7, 5, rock)
pixel(25, 6, rock)
pixel(26, 6, rock)
pixel(26, 5, rock)
end
def draw_chest()
var brown = 0x8B4513
var gold = 0xFFBB00
if self.is_night()
brown = 0x341A08
gold = 0x664400
end
rect_fill(18, 5, 4, 2, brown)
pixel(18, 5, gold)
pixel(19, 5, gold)
pixel(20, 5, gold)
pixel(21, 5, gold)
pixel(20, 6, gold)
end
# --------------------------------------------------
# FISH
# --------------------------------------------------
def draw_fish(x, y, dir, body, tail)
if self.is_night()
body = 0x203040
tail = 0x152030
end
if dir > 0
# tail
pixel(x, y, tail)
# body
pixel(x + 1, y, body)
pixel(x + 2, y, body)
# nose
pixel(x + 3, y, body)
# lower body
pixel(x + 1, y + 1, body)
pixel(x + 2, y + 1, body)
# eye
pixel(x + 2, y, 0xFFFFFF)
else
pixel(x + 3, y, tail)
pixel(x + 1, y, body)
pixel(x + 2, y, body)
pixel(x, y, body)
pixel(x + 1, y + 1, body)
pixel(x + 2, y + 1, body)
pixel(x + 1, y, 0xFFFFFF)
end
end
# --------------------------------------------------
# BUBBLES
# --------------------------------------------------
def draw_bubbles()
var c = 0x44CCFF
if self.is_night()
c = 0x123344
end
pixel(self.bubble1_x, self.bubble1_y, c)
pixel(self.bubble2_x, self.bubble2_y, c)
pixel(self.bubble3_x, self.bubble3_y, c)
end
# --------------------------------------------------
# FOOD
# --------------------------------------------------
def draw_food()
if self.feeding
pixel(self.food_x, self.food_y, 0xFF7722)
end
end
# --------------------------------------------------
# NIGHT DETAILS
# --------------------------------------------------
def draw_sleep()
if !self.is_night()
return
end
# tiny Z above fish
if (now_ms() % 2000) < 1200
var x = self.fish1_x + 2
pixel(x, 0, 0x446688)
if x + 1 < width()
pixel(x + 1, 0, 0x446688)
end
if x + 1 < width()
pixel(x + 1, 1, 0x446688)
end
end
end
# --------------------------------------------------
# MAIN DRAW
# --------------------------------------------------
def draw()
self.update_fish()
self.update_bubbles()
self.update_food()
self.draw_water()
self.draw_sand()
self.draw_plants()
self.draw_rocks()
self.draw_chest()
self.draw_bubbles()
self.draw_fish(
self.fish1_x,
self.fish1_y,
self.fish1_dir,
0xFF7A18,
0xFFB000
)
self.draw_fish(
self.fish2_x,
self.fish2_y,
self.fish2_dir,
0x00BFFF,
0x0066FF
)
self.draw_food()
self.draw_sleep()
end
end
return PixelAquarium()Install it on your AWTRIX NG
Add this flow to your AWTRIX NG. It will start appearing on your display after installation.
Unable to connect? Download the flow and add it in the Scripts section of your AWTRIX. Advanced users can also use this command:
