Balkonkraftwerk Solarwatt

Flow description

# @name    SolarWatt
# @desc    Aktuelle Einspeiseleistung eines Shelly Plug M Gen3, mit Icon je nach Leistungsstufe
# @author  De Douby
# @version 1.3
# @config  ip      text   "Shelly IP-Adresse"       default="192.168.1.50"
# @config  every   number "Aktualisierung"          default=10 min=2 max=60 unit=s
# @config  thigh   number "Schwelle hoch (W)"       default=400 min=0 max=10000
# @config  tlow    number "Schwelle niedrig (W)"    default=100 min=0 max=10000
# @config  chigh   color  "Farbe hoch"              default=#04FE04
# @config  clow    color  "Farbe niedrig"           default=#FF4E1A
# @config  ichigh  text   "Icon-ID hoch"            default="54156"
# @config  icmid   text   "Icon-ID mittel"          default="50557"
# @config  iclow   text   "Icon-ID niedrig"         default="50546"

class SolarWatt
  var url, period
  var watt, label, color, icon_id
  var ticks, in_flight

  def init()
    self.url = "http://" + store.get("ip") + "/rpc/Switch.GetStatus?id=0"
    self.period = store.get("every")
    self.watt = store.get("watt")
    self.label = self.watt == nil ? nil : self.fmt(self.watt)
    self.color = 0xFFFFFF
    self.icon_id = store.get("icmid")
    self.ticks = 0
    self.in_flight = false
  end

  def fmt(w)
    if w >= 1000
      return str(round(w / 1000.0, 2)) + "kW"
    end
    return str(int(w + 0.5)) + "W"
  end

  def on_body(body, status)
    self.in_flight = false
    if body == nil return end
    var m = re.search("\"apower\":([-0-9.]+)", body)
    if m == nil return end
    var w = num(m[1])
    if w == nil return end
    if w < 0 w = -w end                      # Einspeisung liefert negativen Wert -> Betrag nehmen
    self.watt = w
    self.label = self.fmt(w)
    var thigh = store.get("thigh")
    var tlow = store.get("tlow")
    if w > thigh
      self.color = store.get("chigh")
      self.icon_id = store.get("ichigh")
    elif w > tlow
      self.color = 0xFFFFFF
      self.icon_id = store.get("icmid")
    else
      self.color = store.get("clow")
      self.icon_id = store.get("iclow")
    end
    store.set("watt", w)
  end

  def loop()
    if self.ticks <= 0
      self.ticks = self.period
      if !self.in_flight
        self.in_flight = true
        http.get(self.url, / b, st -> self.on_body(b, st), {'find': "\"apower\":", 'keep': 24})
      end
    end
    self.ticks -= 1
  end

  def should_show()
    return self.watt == nil || self.watt > 0    # bei 0W überspringen, vor erstem Fetch trotzdem zeigen
  end

  def draw()
    clear()
    if !icon(self.icon_id, 0, 0)
      rect_fill(0, 0, 8, 8, 0x222222)        # Platzhalter, falls Icon nicht installiert ist
    end
    if self.label == nil
      text(9, 6, "...", 0x666666)
      return
    end
    var w = width() - 9
    text(9 + (w - text_ink_width(self.label)) / 2, 6, self.label, self.color)
  end

  def on_button(btn)
    if btn == "select" self.ticks = 0 end
  end
end

return SolarWatt()
