Air Quality Index from specific site in London

Flow description

# @name    London Air Quality
# @desc    Show per-pollutant Air Quality Index (NO2, O3, PM1, PM2.5, PM10, CO, SO2, NO - whichever the site reports) for a specific location in London, each reading tinted by its London Air band colour. Data feeds comes from Environmental Research Group (ERGP) at Imperial College London. More details on https://www.londonair.org.uk/Londonair/API/ and API documentation https://api.erg.ic.ac.uk/airquality/help
# @author  kowalcj0
# @version 1.2
# @config  site_code  text    "Site Code"  default="BT8"  help="site code, e.g. BT6"
# @config  every  number  "Refresh"  default=30 min=5 max=120 unit=min

import gc

class AirQuality
  # London Air index values 1-10 -> colour, see
  # https://www.londonair.org.uk/london/asp/airpollutionindex.asp
  var levels, url, label, color, opts, err
  # refresh countdown + failure backoff, see due()/failed()/ok()/now()
  var ticks, interval, retry, busy

  def init()
    self.levels = [
      0xADD189, 0x77AD53, 0x2E8405,  # 1-3 low
      0xEFC192, 0xFE9C53, 0xF46200,  # 4-6 moderate
      0xDC1B1B, 0xA70B0B, 0x7B0000,  # 7-9 high
      0xFFFFFF,                      # 10 very high (official black is invisible on the panel)
    ]
    # saving a setting restarts the app, so the URL built here never goes
    # stale. Plain HTTP on purpose: a TLS handshake needs ~45 KB contiguous
    # heap, which this ESP32 can't spare (attempts OOM-panic the device);
    # the ERG API also serves unencrypted, and the payload is public data
    self.url = ""
    var site_code = store.get("site_code")
    if site_code != nil && site_code != ""
      self.url = "http://api.erg.ic.ac.uk/AirQuality/Hourly/MonitoringIndex/SiteCode=" + str(site_code) + "/Json"
    end
    # refresh interval in minutes (hourly feed; keep requests few)
    self.interval = clamp(num(store.get("every"), 0), 5, 120) * 60
    # label is a list of [text, colour] pieces, one per reading; plain
    # string ("--" / "?") until the first successful fetch
    self.label = nil
    self.color = 0x666666
    # marquee over the whole panel; built once, passed every frame
    self.opts = {'mode': "loop", 'speed': 100}
    self.ticks = 0
    self.retry = 30
    self.busy = false
    self.err = false
  end

  # first fetch + fill display state before the first frame
  def setup()
    log("London Air: " + str(gc.allocated()) + " B live in the Berry heap")
    self.loop()
  end

  # select forces a refresh; left and right just rotate
  def on_button(btn)
    if btn == "select"
      self.now()
    end
  end

  def on_body(body, status)
    shared.set("f", 0)
    # non-200 or nil body: nothing usable this attempt
    if status != 200 || body == nil
      log("London Air: fetch failed, status " + str(status))
      self.failed()
      return
    end
    # the find/keep window holds the species list only; the site reports
    # one index per pollutant and which species a site has varies, so every
    # known code is probed, in health-impact order: NO2 nitrogen dioxide,
    # O3 ozone, PM1/PM25/PM10 particulate, CO carbon monoxide, SO2 sulphur
    # dioxide, NO nitric oxide. Each is shown with its own London Air band
    # colour. (A full json.load() of the body would build a tree of ~30
    # small maps/strings per fetch and fragment the tight ESP32 heap.)
    var pieces = []
    for code : ["NO2", "O3", "PM1", "PM25", "PM10", "CO", "SO2", "NO"]
      var pat = "\"@SpeciesCode\":\\s*\"" + code + "\"\\s*,\\s*\"@AirQualityIndex\":\\s*\"(\\d+)\",\\s*\"@AirQualityBand\":\\s*\"([^\"]+)\""
      var m = re.search(pat, body)
      var n = nil
      var band = nil
      if m != nil
        n = num(m[1])
        band = m[2]
      end
      if n != nil && n > 0 && band != nil && band != "No data"
        # display name: PM25 -> "PM2.5"
        var name = (code == "PM25" ? "PM2.5" : code)
        if size(pieces) > 0
          pieces.push([" - ", 0x888888])
        end
        # "NO2 3", tinted by this pollutant's London Air band
        pieces.push([name + " " + str(n), self.band_color(n)])
      end
    end
    if size(pieces) == 0
      log("London Air: no readings in window")
      self.failed()
      return
    end
    self.label = pieces
    self.ticks = self.interval
    self.ok()
    log("London Air: ok, " + str(int(size(pieces) / 2)) + " readings")
  end

  # London Air band colour for a reading (1-10); clamps out-of-range values
  def band_color(n)
    n = int(n)
    if n < 1
      n = 1
    elif n > 10
      n = 10
    end
    return self.levels[n - 1]
  end

  def loop()
    # url checked first: due() raises busy as a side effect
    if self.url != "" && self.due()
      shared.set("f", 1)
      # stream-skip everything before the species list: only a 1 KB window
      # lands on the heap, not the full ~1.4 KB body. 1024 B covers the
      # largest response seen so far (4 species); if a site ever reports
      # more, the tail entries simply don't match and are not shown
      http.get(self.url, / b, st -> self.on_body(b, st), {'find': '"species"', 'keep': 1024})
    end

    # until the first successful fetch: show "--", or "?" once a fetch has
    # failed (see failed())
    if self.label == nil
      self.label = self.err ? "?" : "--"
      self.color = self.err ? 0xCC7722 : 0x666666
    end
  end

  # Fires when the countdown has run down, never while a request is out or
  # another app's TLS handshake is running (shared "f" flag, official
  # convention). Raises busy, so only call it when a request will actually
  # be issued. The countdown is armed by the fetch result (interval on
  # success, backoff on failure).
  def due()
    if self.ticks > 0
      self.ticks = self.ticks - 1
      return false
    end
    if self.busy
      return false
    end
    for k : shared.keys()
      var n = size(k)
      if n > 2 && k[n - 2 .. n - 1] == ".f" && shared.get(k) == 1
        var a = shared.age(k)
        if a != nil && a < 20000
          return false
        end
      end
    end
    # floor: even if the callback never came, the next try is a minute away
    self.ticks = 60
    self.busy = true
    return true
  end

  # failure backoff: retry at 30s, doubling, capped at 5 min; raises err so
  # a fetch with no data yet can show "?" instead of "--"
  def failed()
    self.busy = false
    self.ticks = self.retry
    self.retry = min(self.retry * 2, 300)
    self.err = true
  end

  def ok()
    self.busy = false
    self.retry = 30
    self.err = false
  end

  # manual refresh: clears the countdown but leaves busy alone, so a press
  # while a request is out can't fire a second one
  def now()
    self.ticks = 0
    self.retry = 30
  end

  def draw()
    clear()
    # each reading piece carries its own band colour; the plain "--"/"?"
    # fallback uses the call colour
    scroll_text(0, 6, width(), self.label, self.color, self.opts)
  end
end

return AirQuality()
